4CH NVR 1080P realtime 1HDD 1CH Playback KM7104QC-Buy CCTV Products KVSecurity

4CH NVR 1080P realtime 1HDD 1CH Playback KM7104QC Email to a Friend

SKU: KM7104QC

Market: US$ ~~0.00~~

Price: US $ 65-91

Buy one or more calculated by the wholesale price

Starting from 2 Units

• Based on ONVIF Platform, third-party network cameras supported
• Up to 2 Megapixel resolution recording
• HDMI and VGA output at up to 1920×1080P resolution
• Maximum 4TB Sata HDD
• Group management Per CMS
• Mobile devices view per Smart phone and Tablet
• P2P notification and Push function

Features
Specifications
Dimensions
Application
Payment & Shipping

*H.264 Compression DVR

Video input:
Standard POE
4 CH 1080P without switch
4 CH 1080P IPC by PON(power by NVR) & 1 RJ 45(by switch) (Only for M Series IPC)

100 fps(4 x 25 fps)

4 CH 1080P Recroding + 1 CH realtime Playback

ONVIF,N9 protocol.

Recording mode:Always/Schedule/Alarm recording/Motion detection recording

Audio compression:ADPCM

Dual-stream:Main stream:720P; Sub stream1: VGA/QVGA, Sub stream2: 720P (8FPS);

*Support 1*4TB SATA HDD,1*E-SATA

*IE and Multi-Client software for remote configuration,playback and video data download etc.

*Support mobile phone multi preview+playback+audio+ptz+digital zoom+configuration etc..

System	User Interface	Graphic User interface(OSD Menu)
	OS	Embedded Linux
	ONVIF	Support
	Security	Administrator; Different authurity for users
Video	Video input	Standard POE 4 CH 1080P without switch 4 CH 1080P IPC by PON(power by NVR) & 1 RJ 45(by switch) (Only for M Series IPC)
	Video output	CVBS/VGA/HDMI
	Display	1/4 optional
	VGA	1024768,12801024,1440900,1366768,720P,1080P
	Video encoding resolution	PAL:720P(1280X720); 1080P(19201080) / NTSC:720P(1280X720); 1080P(19201080)
	Video frame rate	PAL: 1-25FPS NTSC:1-30FPS
Audio	Audio compress	ADPCM
	Audio in	IPC with audio
	Audio out	1 out BNC
Image & Storage	Video compress	H.264
	Image quality	720P/1080P
	Sub stream	Sub stream1:VGA/QVGA; Sub stream2:540P
	Resolution	4CH 1080P recording & 1CH realtime playback/4CH Playback(15FPS) 4CH 720P recording & 4CH realtime playback;
	Video Bit Rate	720P:1536kbps-3072kbps;1080P:2048-8192kbps
	Audioo Bit Rate	8—32Kbps
	Storage	1 HDD
Alarm	Alarm in/out	NO
Others	Recording	Manual/alarm/motion detection/timing
	Network	RJ45 1000MB
	Network	Protocol: TCP/IP, PPPOE, SMTP,UPNP,DHCP,DDNS,RTSP
	Voice talk	Support
	Control Method	Remote control, USB mouse, panel control
	Mobile live view	I phone //IPAD/Android/Blackberry
	Domain name server	Support 88110,reelink,3322, dyndns, no-ip, changeip, dnsexit domain name server as default value.
	Backup	USB2.0, Network
Power Supply	NVR	DC 12V 2A (No Built-In Switch) DC 12V 5A (POE For M Series IPC) DC 12V 5A (Standard POE)
Power Supply	IPC	individual power supply(DC 12V 2A) (No Built-In Switch) Power by NVR/individual power supply(DC 12V 2A) (POE For M Series IPC) POE(48V) (Standard POE)
Working Environment		Working temperature: -10℃~+60℃; Working humid:10%~ 90%
Device Dimension		1HDD case:230mm (W)×315mm (D)×40mm (H)
Weight		1HDD Case:≤1.5KG;
