16CH AHD DVR 720P AHD/TVI/960H /IP Hybrid K1016 Email to a Friend

SKU: K1016
Market:  US$    0.00
Price:  US  $ 92-111

Buy one or more calculated by the wholesale price

Starting from 2 Units

Sensor/Alarm:
  • Yes已选中
  • No已选中
TVI:
  • Yes已选中
  • No已选中
HDD:
Quantity: Unit(s)
   Compare   Add to wishlist
Video in: 16ch ; Audio in: 4ch/16ch Video out: VGA / HDMI
IP Cameras: 8 ; PTZ: YES ;
IP-Recording Bandwidth: 24Mbps ~72Mbps
Recording: 1080N(960*1080) :11fps(each ch)
Playback: 1080N/720P 1CH realtime
Dimension: 300X227X53mm/380x340x50mm
Power supply: 12V 2A/5A
Sensor&Alarm: No/4ch/16ch
TVI: Optional
HDD:1HD/2HD
  • Features
  • Specifications
  • Dimensions
  • Application
  • Payment & Shipping
Display Resolution
Analog :1080N/720P/960H
IP:1080P/720P
Record resolution
Analog :1080N/720P/960H
IP:1080P/720P
Record speed
Analog :1080N(960*1080) :10fps(each ch)
720P:10fps(each ch)
960H:PAL:25fps(each ch)/NTSC:30fps(each ch)
IP:PAL:25fps(each ch) /NTSC: 30fps(each ch)
Maximum output Brandwidth
32Mbps
Maximum decode performance
720P:8CH realtime
Recording Mode
Continuous/Manual/Motion detect
HDD interface
2SATA HDD, up to 12TB
Dimension(WxDxH)
378x340x50mm

Model

AHD K1016GS

Video Compression

H.264

Video System

NTSC/PAL

Operation System

Linux(embedded)

Analog video-input /output

16CH inputs / VGA and HDMI output

IP Video Input

8ch,(only IP up to 24ch)

Composite Video Input

up to 24ch (Analog video + IP video)

Audio input /output

16CH inputs /1CH output(RCA)

Display

resolution

Analog :1080N/720P/960H
IP:1080P/720P



feature

1/4/6/8/9/10/13/14/16/17/19/22/25/S.E.Q.

Record

resolution

Analog :1080N/720P/960H
IP:1080P/720P



speed

Analog :1080N(960*1080) :10fps(each ch)
720P:10fps(each ch)
960H:PAL:25fps(each ch)/NTSC:30fps(each ch)
IP:PAL:25fps(each ch) /NTSC: 30fps(each ch)

IP-Recording Bandwidth
(Maximum input Bandwidth)

24Mbps~72Mbps(default is 24Mbps, decrease one Analog channel can increase 3Mbps)

Maximum output Brandwidth

32Mbps

Maximum decode performance

720P:8CH realtime

Recording Mode

Continuous/Manual/Motion detect

Synchronous Playback

16CH

Network Type

Lan, DHCP, and DDNS

HDD interface

2SATA HDD, up to 12TB

Multiplex Operation

live display, record, playback, backup and network

USB

2xUSB(for mouse and backup/upgrade)

Sensor & Alarm I/O

16CH inputs /1CH output

PTZ Control

yes (RS485)

Mobile Surveillance

Support Mobile Phones based on iPhone and Android operation system

VGA/HDMI

1024*768,1280*1024,1440*900,1920*1080

Power Supply

DC 12V/5A

Dimension(WxDxH)

378x340x50mm

Working Temperature

-10°C~+55°C

Working Humidity

10%~90%


Payment Method:

1.TT By Bank:

Beneficiary's Name: FUZHOU GULOU KROVISION TRADING CO.,LTD
Beneficiary's Account No: 43010078814400003252
SWIFT: SPDBCNSH430

2.Western Union:
First name:DENGBIAO
Last name:LU
Country:CHINA

3.Paypal:


Credit Card

Paypal Account: kvspay@gmail.com



Shipping Method:
1.By Express Delivery: DHL,UPS,TNT,Fedex,EMS
Door To Door Service.Take 3-7 business days,used mostly.

2.By Air:

Customer will pick up the cargo at the airport.Take 1-2 weeks.For the weight>100kg.

3.By Post Mail:

Door To Door Service.Take 2-4 weeks.For the weight<2kg.

Shipping Cost:
Please summit your order and offer your contact information:delivery address,telephone/cell phone,receiver...
We should calculate the shipping cost  according to the weight of the shipment.The default shipping way is the cheapest one.


Delivery Date:
Before you place order,please confirm the delivery date with our stuff.
Some items are in stock,the others will be arranged production.
We should report exact date for you after receiving information for the model and its quantity.
