Buy one or more calculated by the wholesale price
Starting from 2 Units
*H.264 Compression DVR |
Video input:16 CH 720P without switch |
16CH 720P recording & 4CH realtime playback; |
ONVIF,N9 protocol. |
Recording mode:Always/Schedule/Alarm recording/Motion detection recording |
Audio compression:ADPCM |
Dual-stream:Main stream:720P; Sub stream1: VGA/QVGA, Sub stream2: 720P (8FPS); |
*Support 2*4TB SATA HDD |
*IE and Multi-Client software for remote configuration,playback and video data download etc. |
*Support mobile phone multi preview+playback+audio+ptz+digital zoom+configuration etc.. |
System |
User Interface |
Graphic User interface(OSD Menu) |
OS |
Embedded Linux |
|
ONVIF |
Support |
|
Security |
Administrator; Different authurity for users |
|
Video |
Video input |
16 CH 720P IPC(by switch) |
Video output |
CVBS/VGA/HDMI |
|
Display |
1/4/6/8/9/10/13/16 optional |
|
VGA |
1024*768,1280*1024,1440*900,1366*768,720P,1080P |
|
Video encoding resolution |
PAL:720P(1280X720); NTSC:720P(1280X720) |
|
Video frame rate |
PAL: 1-25FPS NTSC:1-30FPS |
|
Audio |
Audio compress |
ADPCM |
Audio in |
IPC with audio |
|
Audio out |
1 out RCA |
|
Image |
Video compress |
H.264 |
Image quality |
720P |
|
Sub stream |
Sub stream1:VGA/QVGA; Sub stream2:720P (8FPS) |
|
Resolution |
16CH 720P recording & 4CH realtime playback; |
|
Video Bit Rate |
720P:1536kbps-3072kbps; |
|
Audioo Bit Rate |
8—32Kbps |
|
Storage |
2 HDD |
|
Alarm |
Alarm in/out |
8 in/1 out |
Others |
Recording |
Manual/alarm/motion detection/timing |
Network |
RJ45 1000M |
|
Protocol: TCP/IP, PPPOE, SMTP,UPNP,DHCP,DDNS,RTSP |
||
Voice talk |
Support |
|
Control Method |
Remote control, USB mouse, panel control |
|
Mobile live view |
I phone //IPAD/Android |
|
Domain name server |
Support 88110,reelink,3322, dyndns, no-ip, changeip, dnsexit domain name server as default value. |
|
Backup |
USB2.0, Network |
|
Serial |
RS485 |
|
Power Supply |
NVR |
DC 12V 5A |
IPC |
DC 12V 2A |
|
Working Environment |
Working temperature: -10℃~+60℃; Working humid:10%~ 90% |
|
Device Dimension |
2HDD case:321mm(W)×405mm(D)×64mm(H) |
|
Weight |
2HDD case:3KG |
