◆ H.264 video output real-time
|
Item
|
KDM63
|
|||
|
Detector characteristics
|
Detector
|
Uncooled FPA microbolometer
|
||
|
resolution
|
384×288
|
|||
|
Pitch size
|
25μm
|
|||
|
Spectral range
|
8~14μm
|
|||
|
Thermal Image
|
Focal length
|
9mm
|
18mm
|
37mm
|
|
IFOV
|
2.78mrad
|
1.39mrad
|
0.67mrad
|
|
|
FOV/Min Focus
|
51°×38°/0.1m
|
25°×19°/0.1m
|
12°×9°/0.5m
|
|
|
Thermal sensitivity
|
≤0.06℃@30℃
|
|||
|
Frame Frequency
|
50/60HZ
|
|||
|
Focus
|
Auto/electronic focus/Preset
|
|||
|
Measurement Function
|
Measurement range
|
-20 ℃～+650 ℃
|
||
|
measurement correction
|
Auto/Manual
|
|||
|
Measurement accuracy
|
±2℃ or ±2% of reading, whichever is greater
|
|||
|
Measurement mode
|
Up to 4 movable spots. Up to 3movable areas
|
|||
|
Color Palette
|
11 palettes available(including iron red, rainbow, black/white etc)
|
|||
|
image adjustment
|
Auto/manual Gain, brightness
|
|||
|
Setup function
|
Temperature unit,language,IP address
|
|||
|
Emissivity correction
|
Variable from 0.01to 1.0
|
|||
|
ambient temperature correction
|
Automatic correction according to user input.
|
|||
|
Atmospheric transmission correction
|
automatic correction according to the user input of object distance, relative humidity, ambient temperature
|
|||
|
Image storage
|
Raw image capture
|
Raw images real-time transfer via client control software, the images are analyzable and measureable
|
||
|
Image storage
|
H.264 continuous video. Single image capture BMP
|
|||
|
Power Supply
|
Power in
|
10~15V DC
|
||
|
Power consumption
|
≤7W(@ 25℃normal operation)
|
|||
|
Environment
|
Operating temperature
|
-15℃~ +50℃
|
||
|
Storage temperature
|
-40℃~+70℃
|
|||
|
Encapsulation
|
IP54
|
|||
|
Physical characteristics
|
Weight
|
≤1Kg(Standard lens)
|
||
|
Size
|
W72mm×H76×D232mm(Standard lens)
|
|||
|
Interface
|
Power port
|
YES
|
||
|
Analog video output
|
PAL
|
|||
|
Digital video output
|
RJ-45 Ethernet output(1000Mbit/S)
|
|||
|
Serial Port
|
RS485(optional)
|
|||
|
Item
|
KDM66
|
|||
|
Detector characteristics
|
Detector
|
Uncooled FPA microbolometer
|
||
|
resolution
|
640×480
|
|||
|
Pitch size
|
25μm
|
|||
|
Spectral range
|
8~14μm
|
|||
|
Thermal Image
|
Focal length
|
18mm
|
37mm
|
75mm
|
|
IFOV
|
1.38mrad
|
0.67mrad
|
0.33mrad
|
|
|
FOV/Min Focus
|
51°×38°/0.1m
|
25°×19°/0.1m
|
12°×9°/0.5m
|
|
|
Thermal sensitivity
|
≤0.06℃@30℃
|
|||
|
Frame Frequency
|
50/60HZ
|
|||
|
Focus
|
Auto/electronic focus/Preset
|
|||
|
Measurement Function
|
Measurement range
|
-20 ℃～+650 ℃
|
||
|
measurement correction
|
Auto/Manual
|
|||
|
Measurement accuracy
|
±2℃ or ±2% of reading, whichever is greater
|
|||
|
Measurement mode
|
Up to 4 movable spots. Up to 3movable areas
|
|||
|
Color Palette
|
11 palettes available(including iron red, rainbow, black/white etc)
|
|||
|
image adjustment
|
Auto/manual Gain, brightness
|
|||
|
Setup function
|
Temperature unit,language,IP address
|
|||
|
Emissivity correction
|
Variable from 0.01to 1.0
|
|||
|
ambient temperature correction
|
Automatic correction according to user input.
|
|||
|
Atmospheric transmission correction
|
automatic correction according to the user input of object distance, relative humidity, ambient temperature
|
|||
|
Image storage
|
Raw image capture
|
Raw images real-time transfer via client control software, the images are analyzable and measureable
|
||
|
Image storage
|
H.264 continuous video. Single image capture BMP
|
|||
|
Power Supply
|
Power in
|
10~15V DC
|
||
|
Power consumption
|
≤9W(@ 25℃normal operation)
|
|||
|
Environment
|
Operating temperature
|
-15℃~ +50℃
|
||
|
Storage temperature
|
-40℃~+70℃
|
|||
|
Encapsulation
|
IP54
|
|||
|
Physical characteristics
|
Weight
|
≤1Kg(Standard lens)
|
||
|
Size
|
W72mm×H76×D232mm(Standard lens)
|
|||
|
Interface
|
Power port
|
YES
|
||
|
Analog video output
|
PAL
|
|||
|
Digital video output
|
RJ-45 Ethernet output(1000Mbit/S)
|
|||
|
Serial Port
|
RS485(optional)
|
|||
|
Tripod
|
1/4"-20
|
|||
