4CH 1080P Recording 8pcs SATA HDD 4CH HD SDI DVR KS9204 Email to a Friend

System

User Interface

Graphic User Interface (OSD)

 OS

Embedded Linux

Operation Mode

preview, record, playback, backup, network

Password Security

Multi-level user management

A/V Input

Video input

4 CH SDI Connector

Audio input

4 CH BNC Connector

A/V Output

HDMI output

Supports

720P,1080P,
1024X768,1280X1024, 1366X768,1440X900

VGA output

Supports

Display

1/4 optional

Video standard

PAL/NTSC

Loop

Support

CVBS main output

1CH, BNC connector

Spot output

1CH,BNC  connector

Audio output

1CH,BNC  connector

A/V encoding parameters

Video compression

H.264

Display frame rate

PAL:100 fps(4 x 25 fps).NTSC:120 fps(4 x 30 fps)

Recording frame rate

PAL:100 fps(4 x 25 fps)    NTSC:120 fps(4 x 30fps)

Video encoding resolution

PAL:D1(704X576)/HD1(704X288)/CIF(352X288)/1080P(1920x1080)/720P(1280X720)
NTSC:D1(704X480)/HD1(704X240)/CIF(352X240)/1080P(1920x1080)/720P(1280X720)

Video frame rate

PAL: 1-25FPS  NTSC:1-30FPS

Video bit rate

720P:1536kbps-3072kbps, 1080P:4608-6144kbps,D1:768-1536Kbps,HD1:512-1280kpbs,CIF:384-768kbps,QCIF:192-384kbps

Stream Type

Video & Audio/Video

Audio compression

ADPCM

Recording mode

Always/Schedule/Alarm recording/Motion detection recording

Video search

Time/Channel/Event

Audio bit rate

8—32kbps

Dual-stream

Supports

Mobile phone Monitor

Supports Android phone/iPhone/iPad

Recording resolution

4CH 1080P  Recroding & 4 CH Realtime Playback

HDD

Type

8 pieces SATA

Maximum capacity

4TB for each Sata connector

External connectors

Voice talk

Support, 1CH BNC line in/1CH BNC line out.

Record mode

Audio & Video recording simultaneously

Remote control

Supports

Mouse control

Supports

Network protocol

Supports IE/PPPoE/DDNS

Domain name server

Support 88110,3322, dyndns, no-ip, changeip, dnsexit  domain name server as default value.

Network

1 RJ45 10M/100M/1000M

Serial port

2 RS-485 serial port

RS-232 serial port

E-SATA Connector

Supports

USB Connector

2 USB 2.0

Firmware update

Support USB update/Network update

Alarm input

16 in

Alarm output

4 out

Others

Power supply

ATX

Power (without HDD)

≤70 W

Operation Temperature

-10℃--＋55℃

Operation Humidity

10％--90％

Chassis

Standard 2U

Dimension

440mm(W)×420mm(D)×90mm(H)

Weight(without HDD)

≤6Kg
