Buy one or more calculated by the wholesale price
Starting from 2 Units
■ anti-lightning circuit design
■ professional anti-jamming optical cover
■ High-power infrared transmitter tube and receiving tube
■ included the accessories.
Type | Dual photoelectric detector |
Outdoor detection range | 30/40/60/80/100/150 meters optional |
Number of beams | 2-beam |
Beam frequency | Fixed frequency |
Detection method | 2 beams blocked simultaneously detecting type |
Induction speed | 50-700msec adjustable |
Emitter current (DC12V time) | 8-15MA ( DC12V time ) |
Light receiver operating current (DC12V time) | Alarm 26MA, 45MA static |
Supply Voltage | AC13.8-18V DC12-24V |
Operating Temperature | ﹣25℃-﹢55℃ |
Humidity | ≤95% |
Anti-white light Level | 6500LUX |
Alarm output | 1C relay contact output NO or NC contact capacity AC, DC30V 0.5AMax |
Alarm trigger time | 50-700msec adjustable |
Alarm Duration | 2±1S |
Tamper output | 1B contact output, DC30V/0.5A MAX |
Buzzer Prompt | NO |
Optical adjustment angle (horizontal) | 180°(±90°) |
Optical adjustment angle (vertical) | 20°(±10°) |
Environment adaptive | NO |
Optical Sight | Comes with rifle-type |
Anti-EMI, RFI interference | √ |
The main material | ABS |
Shell material | PC Engineering Plastics |
Enclosure rating | IP55 |
Other additional features | Light indication, OK indication, test terminal |
Size(mm) | 170*78*73 |
