Buy one or more calculated by the wholesale price
Starting from 2 Units
Model No. |
Video Compression |
Chipset Solution |
Description |
720P |
H.264 |
OV9712+HI3518E |
1/4'CMOS,1.0MP |
960P |
IMX225+HI3518C |
1/3'COMS,1.3MP |
|
1080P |
IMX323+HI3516C |
1/2.9'COMS,2.0MP |
|
1080P Starlight |
H.265/H.264 |
IMX291+HI3516D |
1/2.9'COMS,2.0MP |
1080P T-WDR |
IMX290+HI3516D |
1/2.8'CMOS,2.0MP |
|
Model No.
|
K61A
|
Camera
|
Image Sensor
|
1/4" Progressive Scan CMOS
|
Min. Illumination
|
0.01Lux @(F1.2,AGC ON),0Lux with IR
|
|
Shutter
|
Manual /Auto (Adjustable, 1/25~1/100000)
|
|
Lens Type
|
3.6mm, M12 mount (2.8mm,.6mm, 8mm optional)
|
|
Day & Night
|
Auto (ICR) / Color / Black & White
|
|
Compression Standard
|
Video Compression Standard
|
H.264
|
Compression Output Bitrate
|
128Kbps~8Mbps
|
|
Audio Compression Standard
|
PCMV/PCMA
|
|
Audio output Bitrate
|
64Kbps(G.711) /16Kpbs(G.726)
|
|
Max. Resolution
|
Mainstream: 1280×720, Sub-stream : 720×576
|
|
|
Frame Rate
|
50Hz: 25fps(1280×720), 60Hz: 30fps(1280×720)
|
Image Setup
|
Mirror Image, Reverse, Brightness, Contrast, etc.
can be settable on IE browser
|
|
Alarm
|
Motion Detection Alarm
|
|
Network Function
|
Protocols
|
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP,
UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6 |
Interface Protocol.
|
ONVIF
|
|
General Function
|
Flicker Filter, Dual-stream, Mirror Image
|
|
Port
|
Communication Interface
|
RJ45 ( 10M/100M Ethernet), Audio Input /Output optional
|
Application
|
Working Temperature
|
-10℃~50℃
|
Power Supply
|
DC12V±10%
|
|
IR Distance
|
20m (it differs for Lens type & installation environment also )
|
Credit Card
Paypal Account: kvspay@gmail.com
Shipping Method:
1.By Express Delivery: DHL,UPS,TNT,Fedex,EMS
Door To Door Service.Take 3-7 business days,used mostly.
2.By Air:
Customer will pick up the cargo at the airport.Take 1-2 weeks.For the weight>100kg.
3.By Post Mail:
Door To Door Service.Take 2-4 weeks.For the weight<2kg.
Shipping Cost:
Please summit your order and offer your contact information:delivery address,telephone/cell phone,receiver...
We should calculate the shipping cost according to the weight of the shipment.The default shipping way is the cheapest one.
Delivery Date:
Before you place order,please confirm the delivery date with our stuff.
Some items are in stock,the others will be arranged production.
We should report exact date for you after receiving information for the model and its quantity.
