◆ Cooled 320*256 pixel HgCdTe cooled FPA detector
◆ 50HZ full real-time image, ultra long range observation range.
◆ Fast auto focus.
◆ Dual FOVS, meet different range requirements.
◆ Multiple user defined auto mode, meets observation requirement of different targets.
◆ Digital Detail Enhancement(DDE).
◆ Standard interface, easy integration.
◆ IP67 protection encapsulation, nitrogen inside to prevent corrosion, water and dust proof, quakeproof
Item |
Technical specifications |
|
Detector |
Detector type |
HgTeCd Cooled FPA detector |
Array size/format |
320×256 |
|
Image characteristics |
Field of view/min focus distance |
WFOV: 9.2°×7.3°/5m |
Focal length |
240/60mm |
|
Spatial resolution |
WFOV: 0.5mrad |
|
FOV switch time |
≤2s |
|
NETD |
≤20mk@30℃,F2 |
|
Frame frequency |
50HZ |
|
Focus |
Auto/Electrical manual focus |
|
Spectral range |
3.7-4.8μm |
|
Thermal operation |
Starting time |
<8min(In normal temperature 25 degrees) |
Brightness/gain adjustment |
manual brightness/gain adjustment;auto brightness/gain adjustment |
|
auto brightness/gain configuration adjustment |
2 fix pattern,8 user defined setting pattern |
|
Polarity reversal |
Black hot/White hot |
|
zoom |
2x |
|
Noise reduction |
Yes |
|
DDE |
Yes |
|
Calibration |
Automatic and manual calibration |
|
Crosshair |
Display/Hidden |
|
Power system |
External power supply |
24±3V DC |
Power consumption |
<14W(<14W (In normal temperature 25℃ normal work) |
|
Environment |
Operating temperature |
-40℃- +55℃ |
Storage temperature |
-45℃- +65℃ |
|
Encapsulation |
IP67 |
|
Physical Characteristics |
Weight |
≤8Kg |
Dimension |
417mm×147mm×179mm |
|
Interface |
Power interface |
YES |
Video output |
PAL |
|
Communication protocol |
PELCO-D/P , KVS |
|
Remote Control |
RS485 |
