Online observation thermal imaging camera KDS-Buy CCTV Products KVSecurity

Online observation thermal imaging camera KDS Email to a Friend

SKU: KDS

Market: US$ ~~0.00~~

Price: US $ 2485-3023

Buy one or more calculated by the wholesale price

Starting from 2 Units

Lens:

40mm/75mm electrical zoom lens，IP40
◆384×288uncooled sensor
◆Pixle：25um

◆ 384×288, Uncooled FPA microbolometer

◆ 50HZ real time imaging

◆ Thermal image auto focus

◆ Optional brightness/gain configuration adjustment for your easy operation in different

◆ condition of environment

◆ Standard connectors, easy for your integration

Items		KDS40	KDS75
Detector	Detector type	Uncooled FPA microbolometer
	Array size/format	384×288
	Pixel size	25um
	NETD	≤100mK@f/1,300K
	Frame Rate	50Hz
	Wave range	8-14um
Lens	Focal length	40mm	75mm
	IFOV	13.7°*10.3°	7.3°*5.5°
	Lens type	Motorized focus
Measurement	Brightness/gain	Manual brightness/gain; Automatic brightness/manual gain; Automatic brightness/gain
	Polarity reversal	Black hot/white hot
	Electronic zoom	2x
	Calibration	Manual/Auto
	Noise reduction	Yes
	Enhancement	Yes
	Automatic brightness/gain configuration adjustment	2 fixed patterns, 8 user-defined modes
Power supply	External power supply	10-15 V DC
	Power consumption	≤6W（Normal operating at 25℃ ambient temperature condition）
Environment requirement	Work temperature	-20℃-+55℃
	Storage temperature	-45℃-+65℃
Physical characteristics	Weight	≤700g	≤1000g
	Dimension	164mm×63mm×74mm	186.6mm×96mm×96mm
Interface	External power	YES(DC12V±20%)
	Video output	PAL
	Communication interface	RS485（PELCO-D/P）
Observation range	1.8x0.5m Human(detection)	1450m	2700m
	2.3x2.3m Car(detection)	1850m	3480m
	1.8x0.5m Human(Identification)	480m	900m
	2.3x2.3m Car(Identification)	920m	1740m
