◆ 384×288 un-cooled FPA detector
◆ Auto focus
◆ Photo and Record
◆ GPS electronic compass
◆ Laser range finder
◆ Electrical zoom
◆ IP67
Items |
KS750MH |
||
Detector |
Detector type |
Uncooled FPA microbolometer |
|
Spectral range |
8 ~ 14 µm |
||
Array size |
384×288 |
||
Pixel size |
25µm |
||
Machine Characteristics |
NETD |
≤80mk@30℃ |
|
Lens |
Lens |
61mm/F0.8 |
|
Fov |
9.0°×6.75°(±5%) |
||
Image Characteristics |
Brightness enhancement |
Auto/Manual |
|
Image enhancement |
Yes |
||
Filtering |
Yes |
||
Zoom |
2X |
||
Polarity |
Black hot/white hot |
||
Focus |
Auto or electronics focus |
||
Image&video storage |
Storage |
Built-in flash memory |
|
Storage mode |
Photo/record |
||
File format |
JPG/AVI |
||
Storage capacity |
More than 1000 images/2 hours of video |
||
Image Display |
Display |
High definition OLED,800×600,with adjustment |
|
Auto standby |
Sensitive |
||
Information Machine |
GPS |
GPS |
|
Self localization accuracy |
Longitude and latitude7m, Sea level 14m; |
||
Electronic Compass |
Accuracy |
Azimuthal angle 0.6°, Angle of pitch 0.3° |
|
Laser range finder |
Working band |
1.55 µm(safe for human eye) |
|
Distance |
20m~2Km |
||
Accuracy |
≤2m |
||
Range |
≤30m |
||
Success Rate |
≥96% |
||
Working frequency |
3/minute(urgency 10/minute) |
||
Target location accuracy |
±2m(within1Km),±5m(1Km-2Km) |
||
Environment |
Operating temp |
-20℃~+50℃(Standard) |
|
-40℃~+60℃(Specially Made) |
|||
Storage temp |
-40℃~+60℃(Standard) |
||
-40℃~+65℃(Specially Made) |
|||
Encapsulation |
IP67 |
||
Power System |
Battery type |
Li-Ion, rechargeable |
|
Battery operating time |
3 hours continuous working,range detection of 100 times(at normal temperature) |
||
Charging system |
Special designed |
||
Physical |
Weight |
≤2.5KG(include battery) |
|
Dimension |
265(L)mm×210(W)mm× 105(H)mm |
||
Interface |
Power interface |
NA |
|
Video output |
CCIR/PAL |
||
Data transfer |
USB |
||
Remote control |
RS232 |
||
Tripod mounting |
1/4"-20-UNC |
||
Detection Range |
human(1.8*0.5)m |
2000m |
|
car(2.3*2.3)m |
2800m |
||
Recognition Range |
human(1.8*0.5)m |
670m |
|
car(2.3*2.3)m |
935m |
