• CCD
• High resolution, 420-1000 TVL, clear and exquisiteimage
• Low illumination 0.001 Lux @ ( F1.2, AGC ON), 0 Lux with IR
• Support OSD menu control, suitable for customers ownSettings
• Support digital noise reduction function
• Support digital wide dynamic range function
• Support IR SMART
• Support automatic white balance function, high color reduction , and clearimage
• Support back light compensation, apply to monitor in the back lightning environment
• Advanced engineering design ,three axis rotation, high reliability
• IP66 waterproof design, high reliability
• CMOS
• Low illumination 0.1 Lux @ ( F1.2, AGC ON), 0 Lux with IR
• Support ICR, infrared filter automaticallyswitch, automatic color turn black function,
day and night monitoring
• Support automatic white balance, high color reduction, clear image
• Support back light compensation function, apply to monitor in the back lightning environment
• High S/N, image clean and good
• Support automatic electronic shutter, adapt to different environment monitoring
• Support automatic electronic gain function, adaptive brightness
• The advanced double loop glass design, image more clear
• Advanced engineering design, cable built-in bracket, three axis rotation, high reliability
• IP66 waterproof design, high reliability
|
Model
|
CMOSHA
|
CMOSQA
|
SFE3QB
|
SFC3OQ
|
SFV3Q
|
|
Active Pixel
|
728*488
|
976*496
|
P: 976*582
N: 976*494
|
1296*1041
|
P: 976*582
N: 976*494
|
|
Resolution
|
700TVL
|
800TVL
|
700TVL
|
1000TVL
|
800TVL
|
|
Video Out
|
1.0Vp-p Composite Signal (75ohm)
|
|
SYNC
|
Internal
|
|
Sensor
|
PC3089
|
PC1099
|
P: ICX811AK
N: ICX810AK
|
IMX138
|
P:ICX663AK
N:ICX662AK
|
|
Minimum
Illumination
|
0.01Lux
|
0.01Lux
|
0.05Lux
|
0.01Lux
|
0.05 Lux
Sense-Up:
0.01 Lux
|
|
Gama adjust
|
0.45
|
|
Electric
Shutter
|
PAL:1/50s-1/100000s NTSC:1/60s-1/100000s
|
|
S/N Ratio
|
48dB(min)(AGC closed)
|
52dB(min)
|
|
DNR
|
-
|
-
|
2D-DNR
|
3D-DNR
|
|
AWB
|
AUTO
|
AUTO
|
ATW/PUSH/USER1/
USER2/ANTI CR/
MANUAL/PUSH LOCK
|
AUTO
|
ATW/PUSH/USER1/
USER2/ANTI CR/
MANUAL/PUSH LOCK
|
|
AGC
|
AUTO
|
|
BLC
|
-
|
-
|
ON/OFF
|
|
OSD
|
-
|
-
|
YES
|
|
D-WDR
|
-
|
-
|
LOW/MID/HIGH
|
-
|
-
|
|
WDR
|
-
|
-
|
-
|
-
|
OFF/Low/Midlow/
Mid/Midhigh/High
|
|
HLC
|
-
|
-
|
ON/OFF
|
-
|
ON/OFF
|
|
D-Zoom
|
-
|
-
|
-
|
5 Level
|
1-256
|
|
IR-Smart
|
-
|
-
|
ON/OFF
|
-
|
ON/OFF
|
|
Day/Night
|
-
|
-
|
Auto、Color、
B/W、Ext1、Ext2
|
Auto、Ext
|
Auto、Color、Ext
|
|
Motion
Detection
|
-
|
-
|
4 areas optional
|
|
Language
|
-
|
-
|
8 kinds
|
Chinese &
Enghish
|
8 kinds
|
|
Power
Dissipation
|
50mA
|
50mA
|
80mA
|
85mA
|
120mA
|
|
Power Input
|
DC12V±1V
|
|
Color
|
white & dark gray optional
|
|
Operation
Temperature
|
Temperature -10℃～+60℃,Humidity less than 85%RH
|
Application Places
Apply to the financial, supermarket, telecommunications, government, schools, airports, factories, hotels, museums and other places of requirement of high-definition.
