* Designed and produced by RatingSecu, the first rotating bracket.
* 255 degrees horizontal rotate, can set limit position of left and right end as per your application need.
* Built-in intelligent decoder plate, can set preset position, tour scan route, home place.
* Horizontal rotating speed adjustable, 3 levels of 6 ° / sec, or 12 ° / sec, or 20 ° / sec.
* No need complicated wiring, easily upgrade fixed camera to be movable.
* Only need the IPC with RS 485, easily realize to control the bracket via IPC clients, NVR, smart phone APP.
* Use DC 12V power supply + RS 485 control method.
* Can directly connect to our IPC's RS485 and DC 12V power output, provide power to bracket at the same time.
* High quality motor, stable performance and long lifetime.
* Power consumption only DC 12V / 70 mA, use the same power supply with IPC.
* Length 170mm, light and easy use, compatible with most security camera in the market.
* Waterproof, dust-proof, use high quality ABS, can bear weight of 3KG.
Items |
Specification |
Horizontal rotating range |
255 ° |
Horizontal rotating speed |
6 °/ sec, 12 °/ sec, 20 ° / sec |
Tilt rotating range |
60° |
Tilt rotating Speed |
9 ° / sec |
Limit position |
left & right limit positions can be set at will |
Limit position automatically scanning |
Yes, 3 levels speed optional |
Preset |
8 preset positions |
Preset tour routes |
1 tour scan, 3 levels speed optional |
Watch function |
Yes |
Manual place function |
Yes |
Control mode |
RS 485 |
Interface |
DC power + RS 485 |
Power supply |
DC 12V ± 5 % / 100mA |
Power consumption |
0.9 W |
Working environment |
-25℃ -- 55℃,humidity less than 95% (no condensation) |
How to choose a rotating bracket? What situation need us to use rotating bracket?
Intelligent rotating bracket is an helpful tool that developed based on the features of HD IP Camera. When you have project with below situation, we recommend you to use the rotating bracket:
1. The range should be monitored is wide
In many projects, the range need to be monitored is big, like playground, parking lots, hall and cross roads and so on. In order to get a wider visible angle, we usually choose camera with smaller fixed lens, or zoom lens, but zoom lens need high cost, and use small fixed lens, visible image will be very small and lead to reduce the picture effectiveness directly. If choose a big fixed lens, can get better image, but visible angle is small. Now you should choose a rotating bracket, get big visible angle, it will improved the monitoring system effect.
2. Need to monitor wide range and the environment with light reflective at night
Because some places with wide range, when we use IR camera, infrared light reflective at night will impact the video quality, we often use big lens to achieve a better image at night. But if we use small lens, the infrared LED also with small angle, it can see further distance, get more effective image, but because of the small angle, make the camera also can not cover enough space, now we can use rotating bracket to see different spaces via set its preset positions with different angle.
Simple operation command of the rotating bracket
Limit positions scan (set limit position of left and right firstly):
1. Set left limit position: set NO.9 preset
2. Set right limit position: set NO. 10 preset
3. Start limit scan: run / call NO. 12 preset
4. Delete limit scan: set NO. 12 preset
5. Scan speed and manual control have 3 levels optional: set NO. 15 / NO.16 / NO. 17 preset
Tour scan (set preset position firstly)
1. Tour scan route can set 8 preset positions: No. 1 - NO. 8
2. Tour scan route: 1 route
3. Run / call tour scan function: run / call No.13 preset position
4. Delete tour scan route: set No. 13 preset position
5. Tour scan auto check 0 initial position: after run for 50 circles
Home place function (fixed monitoring position, when bracket without any control action, it can automatically back to the home place that you set):
1. Home place preset position: set No.11 preset position
2. Run home place function: run / call No.14 preset position
3. Close home place function: set No.14 preset position
4. Idle time for return to home place: 1 minute
Manually set bracket to automatically check itself : run / call No.18 preset position
Restore factory defaults: set No.20 preset position
Add leading unique functions:
1. Use RS-485 control, no need to identify positive & negative polar for connect RS-485 wires, and, even if you only connect 1 RS-485 wire can realize control.
2. If power is cut down suddenly, the bracket will not lose data, after power on again, it will automatically continue the action before power off.
3. Manually set address code is available, steps:
-- set NO. 25 preset position
-- press “set preset” key of keyboard / NVR / software + address code number
-- press “ENTER” / “ok” TO SAVE SETTING.
-- After change address code of bracket, please also change the control device’s address code, to realize control.
-- set NO. 26 preset position, save the new address code, then reboot the bracket. If you don’t do this operation, after reboot the bracket, it will automatically back to its previous address code.
* Can decrease camera quantity in project, then decrease project cost, let integrator have more advantages than their competitor.
* Specially suitable for indoor, change camera's visible range to be wide and improve definition.
E.g. When you want wide angel indoor, you often choose a 3.6mm lens camera, but the definition can not be very good, if you choose a 6mm lens camera with this PT bracket, definition is better, although the 6mm lens can not reach the angle of 3.6mm lens, but the PT bracket make the biggest monitoring range to be 255 degrees.
* Competitive price, only designed by us, unique but easy to use, help your installation to be easier, gain more praises from users.
