Buy one or more calculated by the wholesale price
Starting from 2 Units
*H.264 Compression DVR |
Video input: 8 CH 720P without switch 8 CH 720P IPC by PON(power by NVR) & 1 RJ 45(by switch) (Only for M Series IPC) |
200 fps(8 x 25 fps) |
8 CH 720P Recroding &4 CH realtime (full frame) Playback/ 8 CH realtime (15FPS) playback; |
ONVIF,N9 protocol. |
Recording mode:Always/Schedule/Alarm recording/Motion detection recording |
Audio compression:ADPCM |
Dual-stream:Main stream:720P; Sub stream1: VGA/QVGA, Sub stream2: 720P (8FPS); |
*Support 1*4TB SATA HDD,1*E-SATA |
*IE and Multi-Client software for remote configuration,playback and video data download etc. |
*Support mobile phone multi preview+playback+audio+ptz+digital zoom+configuration etc.. |
System |
User Interface |
Graphic User Interface (OSD) |
||
OS |
Embedded Linux |
|||
Operation Mode |
preview, record, playback, backup, network |
|||
Password Security |
Multi-level user management |
|||
ONVIF |
Support |
|
||
A/V Input & output |
Video input |
8 CH 720P without switch 8 CH 720P IPC by PON(power by NVR) & 1 RJ 45(by switch) |
||
HDMI output |
Supports |
720P,1080P, |
||
VGA output |
Supports |
|||
Display |
1/4/6/8/9 optional |
|||
Video standard |
PAL/NTSC |
|||
CVBS main output |
1CH, BNC connector |
|||
Audio output |
1CH,RCA connector |
|||
A/V encoding parameters |
Video compression |
H.264 |
||
Display frame rate |
PAL:200 fps(8 x 25 fps).NTSC:240 fps(8 x 30 fps) |
|||
Recording frame rate |
PAL:200 fps(8 x 25 fps) NTSC:240 fps(8 x 30fps) |
|||
Video encoding resolution |
PAL:720P(1280X720); NTSC:720P(1280X720) |
|||
Video frame rate |
PAL: 1-25FPS NTSC:1-30FPS |
|||
Video bit rate |
720P:1536kbps-3072kbps; |
|||
Stream Type |
Video & Audio/Video |
|||
Audio compression |
ADPCM |
|||
Recording mode |
Always/Schedule/Alarm recording/Motion detection recording |
|||
Video search |
Time/Channel/Event |
|||
Audio bit rate |
8—32kbps |
|||
Dual-stream |
Main stream:720P; Sub stream1: VGA/QVGA, Sub stream2: 720P (8FPS); |
|||
Mobile phone Monitor |
Supports Android phone/iPhone/iPad/Black berry |
|||
Recording resolution |
8 CH 720P Recroding &4 CH realtime (full frame) Playback/ 8 CH realtime (15FPS) playback; |
|||
HDD |
Type |
1 pieces SATA |
||
Maximum capacity |
4TB for each Sata connector |
|||
External connectors |
Voice talk |
Support, 1CH BNC line in/1CH RCA audio out. |
||
Record mode |
Audio & Video recording simultaneously |
|||
Remote control |
Supports |
|||
Mouse control |
Supports |
|||
Network protocol |
Supports IE/PPPoE/DDNS/RTSP |
|||
Domain name server |
Support 88110,reelink,3322, dyndns, no-ip, changeip, dnsexit domain name server as default value. |
|||
Network |
1 RJ45 10M/100M |
|||
USB Connector |
2 USB 2.0 |
|||
Firmware update |
Support USB update/Network update |
|||
Alarm input |
NO |
|||
Alarm output |
NO |
|||
Others |
Power supply |
NVR: DC 12V 2A (No Built-In Switch) DC 12V 8A (POE For M Series IPC) |
||
IPC: DC 12V 2A (No Built-In Switch) PON(power over NVR mainboard) / individual power supply(DC 12V 2A) (POE For M Series IPC) |
||||
Operation Temperature |
-10℃--+55℃ |
|||
Operation Humidity |
10%--90% |
|||
Chassis |
Standard 1U |
|||
Dimension |
230mm (W)×315mm (D)×40mm (H) |
|||
Weight(without HDD) |
≤1.5Kg |
8 CH 720P without switch
8 CH 720P IPC by PON(power by NVR) & 1 RJ 45(by switch) (Only for M Series IPC)
Credit Card
Paypal Account: kvspay@gmail.com
Shipping Method:
1.By Express Delivery: DHL,UPS,TNT,Fedex,EMS
Door To Door Service.Take 3-7 business days,used mostly.
2.By Air:
Customer will pick up the cargo at the airport.Take 1-2 weeks.For the weight>100kg.
3.By Post Mail:
Door To Door Service.Take 2-4 weeks.For the weight<2kg.
Shipping Cost:
Please summit your order and offer your contact information:delivery address,telephone/cell phone,receiver...
We should calculate the shipping cost according to the weight of the shipment.The default shipping way is the cheapest one.
Delivery Date:
Before you place order,please confirm the delivery date with our stuff.
Some items are in stock,the others will be arranged production.
We should report exact date for you after receiving information for the model and its quantity.
