*H.264 Compression DVR |
PAL:D1(704X576)/HD1(704X288)/CIF(352X288)/1080P(1920x1080)/720P(1280X720) NTSC:D1(704X480)/HD1(704X240)/CIF(352X240)/1080P(1920x1080)/720P(1280X720) |
Recording resolution:8 CH 1080P Recroding + 1 CH 1080P realtime Playback |
*Video Input:8 CH SDI Connector,Audio Input:8 CH BNC Connector |
Audio Output:1CH,BNC connector,spot output:1CH,BNC connector,CVBS main output:1CH,BNC connector;16in/5out alarm,HDMI |
support voice talk, |
Audio compression:ADPCM |
Power supply:12V 5A |
*Support 2*2TB SATA HDD,1*E-SATA |
*IE and Multi-Client software for remote configuration,playback and video data download etc. |
*Support mobile phone multi preview+playback+audio+ptz+digital zoom+configuration etc.. |
System |
User Interface |
Graphic User Interface (OSD) |
|
OS |
Embedded Linux |
||
Operation Mode |
preview, record, playback, backup, network |
||
Password Security |
Multi-level user management |
||
A/V Input |
Video input |
8 CH SDI Connector |
|
Audio input |
8 CH BNC Connector |
||
A/V Output |
HDMI output |
Supports |
720P,1080P, |
VGA output |
Supports |
||
Display |
1/4/6/8/9optional |
||
Video standard |
PAL/NTSC |
||
|
NO |
||
CVBS main output |
1CH, BNC connector |
||
Spot output |
1CH,BNC connector |
||
Audio output |
1CH,BNC connector |
||
A/V encoding parameters |
Video compression |
H.264 |
|
Display frame rate |
PAL:100 fps(4 x 25 fps).NTSC:120 fps(4 x 30 fps) |
||
Recording frame rate |
PAL:100 fps(4 x 25 fps).NTSC:120 fps(4 x 30fps) |
||
Video encoding resolution |
PAL:D1(704X576)/HD1(704X288)/CIF(352X288)/1080P(1920x1080)/720P(1280X720) |
||
Video frame rate |
PAL: 1-25FPS NTSC:1-30FPS |
||
Video bit rate |
720P:1536kbps-3072kbps, 1080P:4608-6144kbps,D1:768-1536Kbps,HD1:512-1280kpbs,CIF:384-768kbps,QCIF:192-384kbps |
||
Stream Type |
Video & Audio/Video |
||
Audio compression |
ADPCM |
||
Recording mode |
Always/Schedule/Alarm recording/Motion detection recording |
||
Video search |
Time/Channel/Event |
||
Audio bit rate |
8—32kbps |
||
Dual-stream |
Supports |
||
Mobile phone Monitor |
Supports Android phone/iPhone/iPad |
||
Recording resolution |
8CH 1080P Recroding & 1CH realtime Playback/4 CH Playback(P:13FPS,N:15FPS)/8 CH playback(P:7FPS,N:8FPS) |
||
HDD |
Type |
2 pieces SATA |
|
Maximum capacity |
4TB for each Sata connector |
||
External connectors |
Voice talk |
Support |
|
Record mode |
Audio & Video recording simultaneously |
||
Remote control |
Supports |
||
Mouse control |
Supports |
||
Network protocol |
Supports IE/PPPoE/DDNS |
||
Domain name server |
Support 88110,3322,reelink, dyndns, no-ip, changeip, dnsexit domain name server as default value. |
||
Network |
1 RJ45 10M/100M/1000M |
||
Serial port |
2 RS-485 |
||
E-SATA Connector |
Supports |
||
USB Connector |
2 USB 2.0 |
||
Firmware update |
Support USB update/Network update |
||
Alarm input |
8 in |
||
Alarm output |
2 out |
||
Others |
Power supply |
DC12V 5A |
|
Operation Temperature |
-10℃--+55℃ |
||
Operation Humidity |
10%--90% |
||
Chassis |
Standard 1.1U |
||
Dimension |
321mm(W)×405mm(D)×55 mm(H) |
||
Weight(without HDD) |
≤2.5Kg |
