2.0 Megapixels 1080P HD IP Box Camera KR1H3B Email to a Friend

Camera

Image Sensor

1/2.9" Progressive Scan 2.0 Megapixel CMOS
1/2.8" Progressive Scan 3.0 Megapixel CMOS WDR

Effective Pixel

1920(H)×1080(V)

Min Illumination

Color 0.001Lux@（F1.2 AGC ON）；B/W 0Lux@（F1.2 AGC ON）

(Super EX-view)

Color 0.01Lux@（F1.2 AGC ON）；B/W 0Lux@（F1.2 AGC ON）

S/N Ratio

≥50db(AGC OFF)

3A Control

AWB/AGC/Auto Exposure

Electronic Shutter

1/25—1/10000s

IR Distance

N/A

Waterproof

N/A

Audio&Video Encoding

Video Encoding

H.264 High Profile Encoding

Streams

First Stream：1920*1080，1-30fps；1280*720，1-30fps;

Second Stream：1280*720，1-30fps;704*576，1-30fps;

Third Stream：352*288，1-30fps；176*144，1-30fps;

Video Compression

32Kbps～16Mbps，Support CBR/VBR

Video Text

Channel Name、Time&Date

Audio Compression

G.711

I/O

Lens

Optional

Audio

Support

Alarm

Support

RS485

Support

Internet

10/100M Auto Adaptive，RJ45

Data Transfer and Storage

Data Storage

Video、Picture

Storage Type

Manual、Auto(Timing、Probe、Motion、Block Detection)

Alarm Message

E-mail、IE、Management Software

Internet Protocol

TCP/IP、UDP、RTP、RTSP、RTCP、HTTP、DNS、DDNS、DHCP、NTP、PPPOE、SMTP、UPNP

Onvif

Support

Web View

IE 6.0 above

Working Status

Power Supply

DC12V/2A

Working Environment

Temperature: -10℃ to +55℃;

Humidity: 0% - 90%
